جديد ماكينة تشقيب المعدن MTP B5016C

METAL SHAPING MACHINE B5016C – 160 MM STROKE

Metal Technics Polska – MTP B5016C

Machine Data

Machine description/name:
METAL SHAPING MACHINE B5016C – 160 MM STROKE

Manufacturer:
Metal Technics Polska

Model:
MTP B5016C

Year of manufacture: 2026
Condition: new
Technical condition: fully operational

Price and Location

EXW – fixed price plus VAT: €7,125

Location:
Fabryczna 1, 08-300 Sokołów Podlaski, Poland

Technical Specifications
Total weight: 1400 kg
Power: 1.5 kW (2.04 HP)
Input voltage: 400 V
Overall length: 1270 mm
Overall width: 1100 mm
Overall height: 1700 mm
Maximum workpiece weight: 300 kg
X-axis travel: 360 mm
Y-axis travel: 320 mm
Z-axis travel: 160 mm
Spindle motor power: 1500 W
Maximum product height: 320 mm
Input current type: three-phase
Warranty period: 12 months
Description

Special offer – 5% discount!

B5016C Shaping Machine – 160 mm Stroke

The Metal Technics Polska B5016C shaping machine is a professional industrial machine designed for producing keyways, splines, internal grooves and other precision shaping operations. Thanks to its solid construction, rotary table and precise ram movement, the machine provides high machining accuracy, reliability and long service life.

The machine is ideal for tool rooms, maintenance departments and manufacturing plants. The maximum 160 mm stroke, 360° rotary table and 4.5 kN shaping force enable a wide range of precision machining operations.

Main Features
160 mm stroke
Robust industrial construction
Ø350 mm rotary table
360° table rotation
Vertical ram adjustment
4.5 kN shaping force
High machining accuracy
CE certificate
Technical Specifications
Model: B5016C
Maximum stroke: 160 mm
Number of strokes: 23 / 32 / 44 / 48 / 67 / 92 strokes/min
Table diameter: 350 mm
Vertical ram adjustment: 160 mm
Distance from tool holder to column: 485 mm
Distance from table to ram: 320 mm
Longitudinal table travel: 360 mm
Cross table travel: 320 mm
Table rotation: 360°
Maximum tool cross-section: 25 × 40 mm
Maximum table load: 300 kg
Maximum shaping force: 4.5 kN
T-slot width: 14 mm
Main motor power: 1.5 kW
Machine dimensions: 1270 × 1100 × 1700 mm
Weight: 1400 kg
Applications
Keyway production
Spline machining
Internal groove production
Precision shaping
Tool rooms
Maintenance departments
Metalworking workshops
Manufacturing plants
Transport and Delivery

The machine is brand new and comes with a 12-month warranty. The package includes a CE declaration of conformity, technical documentation, as well as professional warranty and post-warranty service. We also ensure continuous availability of spare parts.

We offer professional transportation throughout Europe using specialised companies experienced in transporting industrial machinery. Each machine is properly secured for transport and delivered directly to the customer.

We also provide assistance with export documentation and international transportation. Upon request, we can also arrange delivery to countries outside Europe.

About Metal Technics Polska

Metal Technics Polska is a manufacturer and distributor of professional metalworking machinery. We provide technical consulting, spare parts and comprehensive after-sales service.

Contact us to obtain the price, delivery time, machine availability or an individual quotation.
